TECHNICAL SPECIFICATIONS
 Optical format
1/4 inch color CMOS
 TV system
NTSC
 H-FOV
170
 Pixel array
648 (H) x 488 (V)
 Frame rate
60 fps
 Temperature
-30/80 C
IN THE BOX
XB1ZCAMHD00
Rear camera
PATCH CABLES
V02551170 Single AiM rear camera patch cable
V02573410 Double AiM rear camera patch cable
V02573390 Single non AiM rear camera patch cable
V02573400 Double non AiM rear camera patch cable
